4W - 7W
phase-dim LED Driver for 150 / 350 / 500 / 700 mA,
with low ripple
| Model | Vin | lout | Vout | Pout | Power Factor | Current Ripple | Dimension | Certification |
|---|---|---|---|---|---|---|---|---|
| G5RT7W150LR-S | 220 - 240 V | 150 mA | 30 - 42 V | 4.5 - 6.3 W | 0.9C | ± 5 % | Φ48 x 25 mm | CE |
| G5RT7W350LR-S | 220 - 240 V | 350 mA | 12 - 22 V | 4.2 - 7.7 W | 0.9C | ± 5 % | Φ48 x 25 mm | CE |
| G5RT7W500LR-S | 220 - 240 V | 500 mA | 9 - 13 V | 4.5 - 6.5 W | 0.9C | ± 5 % | Φ48 x 25 mm | CE |
| G5RT7W700LR-S | 220 - 240 V | 700 mA | 6 - 9 V | 4.2 - 6.3 W | 0.9C | ± 5 % | Φ48 x 25 mm | CE |
Phase dimmable LED Driver for constant 150 / 350 / 500 / 700 mA
Dimming Range : 10-100 %
Average service life 50,000 h
Operating ambient temperature -20°C - +50°C
Ripple current ±5%
Protection:
1. Short- & open circuit proof
2. Auto. overheat regulation or cut off
3. Overload protection
4. SELV
| Datasheet | G5RT7WxxxLR-S |
| EU Declaration of conformity | CE_G5RT7WxxxLR-S |
