2023-09-01
New product DM - LWC series
①
②
15 W 19 W / 13 W 25 W 34 W 44 W
• In-track recess adaptor drivers supported constant current
output for single chip & COB LED specs.
• Current adjustable via Dip switch with 250-1050 mA on
different occasions. a single luminaire can meet the needs
of different illumination applications in the environment.
effectively reduce the inventory management of models with
different currents.
• High quality light output of low ripple≦ ±3%,≦ ±5% brings
a comfort of visual environment.
• Protection fits for class II luminaires.
• 50,000 hrs of lifetime offers 5-year product warranty.
• Comply with 2019/2020 New Eco-Design New Erp instruction
PstLM, SVM , CE, UKCA compliance.
• Suitably promote in areas such as high-end shop, museum,
super market.
4 wire 3 phase LED track rail
• Designed compatibly with
STUCCHI, POWERGEAR and
other brands on 3-phase-circuit
track system,
© HEP 23-08-22-EN
H E P T E C H CO . , LT D .
Taiwan Stock Code 3 6 0 9
www.hepgroup.net
In-Track Recess Adaptor Drivers : Mini Type
Constant Current Drivers
[ SVM ≦ 0.4 ] [ PstLM ≦ 1 ]
Vin : 220-240 Vac
①
②
Model
Prated
Irated
Urange
PF
Ripple
Certification
Size
138.9 x 30.9 x 43 (mm)
WH / BK
LWC19W500CALR-S
LWC23W600CALR-S
LWC44W1050CALR
162 x 30.9 x 43.1 (mm)
WH / GY / BK
LWC25W600CALR
LWC34W800CALR
LWC15W350CALR
7.5 - 9.5 W
250 mA
10.5 - 13.3 W
350 mA
12.0 - 15.2 W
400 mA
15.0 - 19.0 W
500 mA
10.5 - 13.3 W
350 mA
13.5 - 17.1 W
450 mA
15.0 - 19.0 W
500 mA
18.0 - 22.8 W
600 mA
30 - 38 V
0.8-0.9
±5 %
CE/UKCA
30 - 38 V
0.7-0.9
±5 %
CE/UKCA
5.4 - 8.4 W
200 mA
6.8 - 10.5 W
250 mA
8.1 - 12.6 W
300 mA
9.5 - 14.7 W
350 mA
12.2 - 18.9 W
450 mA
13.5 - 21.0 W
500 mA
14.9 - 23.1 W
550 mA
16.2 - 25.2 W
600 mA
17.6 - 27.3 W
650 mA
18.9 - 29.4 W
700 mA
20.3 - 31.5 W
750 mA
21.6 - 33.6 W
800 mA
23.0 - 35.7 W
850 mA
24.3 - 37.8 W
900 mA
27.0 - 42.0 W
1000 mA
28.4 - 44.1 W
1050 mA
CE/UKCA
27 - 42 V
0.85-0.96
±3 %
CE/UKCA
0.9-0.96
±3 %
27 - 42 V
0.85-0.96
±3 %
CE/UKCA
27 - 42 V
27 - 42 V
CE/UKCA
0.7-0.96
±3 %
Efficiency
92 %
92 %
88 %
88 %
88 %
88 %
Please click here to download the PDF file
